This comprehensive list includes all the parts required to assemble a Lemontron Rev E 3D printer. Parts that need trimming, cutting, etc. are marked with MOD.
Positron Parts
Hardware
Electronics
Optional Upgrades
Screws ($13.06)
There are only 7 types of screws used.
M3
14mm
×37
Top Plates
×5
Fans
×16
Z Idler
×2
X Idlers
×2
AC Plug
×2
A/B Idlers
×2
Bearing Tower
×2
Z-Block
×2
Bed Holder
×2
Tool Head
×2
M3
8mm
×24
Z-Rail
×6
Lemonstruder
×1
Motors
×6
Lead Nut
×3
Risers
×4
Clip
×2
Tensioner
×2
M3
20mm
×25
Y-Rail
×10
XY Spacer
×2
Mid Plates
×2
Top Plates
×4
Bed Screws
×2
Bed Holder
×5
The NEW badge is for current owners of a JourneyMaker who wish to convert it to a Lemontron. The cost for the NEW parts is $47.01, plus another stepper motor. If you’re converting a JourneyMaker, you can re-use your entire tool head, so you don’t need to buy the positron one but it’s a big upgrade.
